The MikroTik LHG 5 (RBLHG-5nD) 5GHz, 24.5dBi, Dual Chain 802.11an wireless, 600MHz CPU, 64MB RAM, 1x LAN, POE, PSU, RouterOS L3 antenna access point is an outdoor, compact, and lightweight access point operating in the 5 GHz frequency band. It supports the 802.11 a/n wireless standard and the NMA TDMA protocol, making it an ideal solution for creating stable and high-performance wireless connections. Thanks to its design and characteristics, this device is effectively used for data transmission over significant distances.
This model is perfectly suited for organizing point-to-point connections, providing a reliable bridge between two remote network segments. Additionally, it can be used as client equipment (CPE), connecting end-users to a remote access point or base station, especially where a stable long-distance connection is required. The high antenna gain and support for modern communication standards allow for high throughput and minimal latency.
Key features of the MikroTik LHG 5 (RBLHG-5nD) antenna access point
| Characteristic | Value |
|---|---|
| Device Type | Outdoor Access Point / Antenna |
| Operating Frequency | 5 GHz |
| Wireless Standard | 802.11 a/n |
| MIMO | 2x2 Dual Chain |
| TDMA Protocol | NMA TDMA |
| Antenna Gain | 24.5 dBi |
| Beamwidth | 11 degrees |
| Max Output Power | 25 dBm |
| Processor | AR9344 |
| CPU Cores | 1 |
| CPU Clock Speed | 600 MHz |
| RAM | 64 MB |
| Flash Memory | 16 MB |
| Network Ports | 1 x 10/100 Ethernet |
| Power Supply | PoE (Power over Ethernet) |
| Operating System | RouterOS |
| RouterOS License Level | Level 3 |
| Operating Temperature Range | from -40°C to +70°C |
| Dimensions | Ø40cm |
| Weight | 560g |
Advantages of the MikroTik LHG 5 (RBLHG-5nD) antenna access point
The MikroTik LHG 5 (RBLHG-5nD) antenna access point offers a number of significant advantages, making it an attractive choice for various wireless network deployment scenarios. The high antenna gain of 24.5 dBi combined with Dual Chain technology provides a powerful signal and high throughput, which is critically important for stable long-distance connections. Support for the NMA TDMA protocol allows for efficient use of airtime, especially in high-client density environments, improving overall network performance. The compact and lightweight design simplifies device mounting and installation. The built-in RouterOS Level 3 operating system provides basic routing and traffic management capabilities, allowing the device to be used as a standalone network element. A wide operating temperature range ensures reliable operation of the MikroTik LHG 5 (RBLHG-5nD) antenna access point in extreme climatic conditions.
Features of MikroTik LHG 5
Features of the MikroTik LHG 5 include an integrated antenna and radio module design in a single housing, which minimizes signal loss over the cable and simplifies the installation process. The parabolic antenna shape provides a narrow beam, increasing signal directivity and reducing interference from the sides. The device is powered by Power over Ethernet (PoE) technology, allowing data and power to be transmitted over a single Ethernet cable, simplifying installation, especially in hard-to-reach locations. The use of a high-performance AR9344 processor with a clock speed of 600 MHz and 64 MB of RAM provides sufficient computing power for basic network tasks and stable device operation under load.
Useful functions
- Point-to-point operation mode
- CPE (client) operation mode
- Basic routing functions (RouterOS Level 3)
- Support for 802.11 a/n wireless communication protocols
- Use of NMA TDMA protocol for efficient spectrum utilization
- Remote management and monitoring capabilities via RouterOS
MikroTik RBLHG-5nD Compatibility
MikroTik RBLHG-5nD compatibility is ensured by supporting standard 802.11a and 802.11n wireless communication protocols, allowing it to work with a wide range of other network equipment that supports these standards. In particular, it can interact with other MikroTik devices operating in the 5 GHz band and supporting the relevant protocols to build wireless bridges or networks. Also, as client equipment, it is compatible with base stations or access points from other manufacturers if they comply with the same standards and operate at 5 GHz. PoE power technology also ensures compatibility with injectors and switches that support this power standard.
MikroTik LHG 5 (RBLHG-5nD) antenna access point package contents
Standard package includes:
- MikroTik LHG 5 (RBLHG-5nD) antenna access point - 1 pc.
- K-LHG kit - 1 pc.
- PoE injector for power supply via Ethernet cable - 1 pc.
- 24V, 0.38A power adapter for 220V mains connection - 1 pc.
- Metal clamps - 2 pcs.
Packaging
The antenna access point is typically packaged in a cardboard box, which protects the device and its components during transportation. Internal packaging elements may include foam inserts or other materials to secure the device and prevent damage. The box usually indicates the model name, key characteristics, and manufacturer information.
Purchasing the MikroTik LHG 5 (RBLHG-5nD) antenna access point will be an excellent solution for creating reliable and high-performance long-distance wireless connections. This device combines a high-quality antenna, a powerful radio module, and a functional RouterOS operating system, making it a versatile tool for network construction. Don't miss the opportunity to improve your wireless infrastructure with MikroTik LHG 5.
