Foxeer Wildfire 5.8GHz 72CH Video Receiver
Foxeer Wildfire 5.8GHz 72CH — a professional FPV video receiver designed for racing and freestyle drone pilots who value signal reliability, high sensitivity, and ease of setup. Brand: Foxeer. Product type: Drones & Quadcopters > Transmitters. Wildfire combines dual reception, a wide range of channels, and modern interfaces for use with various generations of goggles.
Key Features
- Dual Receiver: two independent RF modules allow simultaneous connection of two antennas for increased stability and interference resistance.
- 72 Channels (5.8 GHz): compatibility with a large number of transmitters and video systems on the 5.8 GHz frequency provides flexibility in setting up your system.
- Firmware Updates: support for updates allows you to receive new features and timely fixes from the manufacturer.
- Built-in OSD: displays channel frequency, RSSI, battery status, and other key parameters directly in your FPV goggles.
- Wide Power Range: compatible with 5–16 V power sources, which facilitates integration into various equipment configurations.
In addition, Wildfire is equipped with an OLED screen for easy menu navigation and a 5-way button for quick channel selection and settings. The device uses sensitive RF modules with a sensitivity threshold of up to -98 dBm, allowing reliable reception of weak signals at a distance and in noisy conditions.
| Features | Parameters |
|---|---|
| Sensitive receiver modules used | -98dBm |
| OLED screen | Yes |
| OSD and firmware update support | Yes |
| 5-way button | Yes |
| Input voltage | 5~16V |
| Cooler | 1504 (Taiwan production) |
Technical Specifications
| Specifications | Parameters |
|---|---|
| Brand | Foxeer |
| Model | Wildfire |
| Compatibility | all Fatshark goggle versions (V1, V2, V3, HD1, HD2, HD3, SE, HDO, HDO2) |
| Frequency | 5.8G |
| Number of channels | 72 |
| RF sensitivity | -98dBm |
| Power consumption | 5V 400mA±10% |
| Required power | 5~16V |
| Color | option selection |
| Weight | 30g |
Pilot Benefits: thanks to its dual reception architecture and high RF sensitivity, Wildfire guarantees a stable image even in dense RF environments. The built-in OSD allows real-time monitoring of RSSI, selected frequency, and battery status directly in the goggles, which is critical during long training sessions and competitions. The ability to update firmware ensures the functionality remains current and compatible with new standards.
Package Contents:
- 1 x Foxeer Wildfire 5.8GHz 72CH Receiver Module
This video receiver will be an excellent choice for those looking for a versatile, reliable, and easy-to-use solution for FPV systems. Compatibility with all popular Fatshark goggle versions and support for a wide range of channels make Wildfire a flexible component in your equipment setup.
