Carbon XL Frame

The Carbon XL Frame is a lightweight, strong, and reliable structure for assembling medium and large-sized quadcopters. It is ideal for racing and freestyle drones where rigidity and minimal weight are crucial. Manufacturer: China. Category: Drones & Quadcopters > Frames. The frame ensures easy assembly and wide compatibility with standard components, allowing you to build a balanced aircraft for various tasks.

Specifications:

• Motor-to-motor size: specified in option (232/294/390 mm)
• Material: carbon
• Arm thickness: 4 mm
• Main plate: 2 mm
• Camera mounting distance: 22 mm (min)
• Height: 23 mm (supports 2-layer stacks)
• Aluminum standoffs: M3x28 mm
• Stack mounting holes: 30.5 x 30.5 mm M3 / M4
• Propellers: not included
• Motors (recommended): 2204 (for XL5 configuration), 2212-2306 (for XL9 configuration)
• ESC (recommended): from 20A (for XL5), 30-60A (for XL9)
• Battery (recommended): 1550 mAh (for XL5), 3300 mAh (for XL9)
• Weight: specified in option (116 / 131 / 154 g)

The Carbon XL frame is made of high-quality carbon with 4 mm thick arms and a 2 mm main plate, ensuring excellent rigidity with minimal mass. The 23 mm height allows for two layers of electronics (2-layer stacks), and the 30.5 x 30.5 mm M3/M4 mounting holes make it compatible with most flight controllers and expansion boards. M3x28 mm aluminum standoffs provide additional strength and structural stability.

The universal frame geometry with 232/294/390 mm options allows you to choose the optimal size for your tasks: a compact option for quick maneuvers or a larger one for stability and endurance with larger batteries. Recommended motors and ESCs suggest optimal thrust and power parameters: for smaller configurations, 2204 motors and ESCs from 20A are suitable, while for larger ones, 2212-2306 motors and 30-60A ESCs are recommended. Recommended 1550 mAh and 3300 mAh batteries will help achieve a balance between weight and flight time.

The frame is supplied without propellers; pay attention to the correspondence of propeller diameter and pitch to the selected motors. The weight in the options (116/131/154 g) allows for easy calculation of the total aircraft mass when selecting components.

If you are looking for a reliable base for your quadcopter with the ability to install two-layer stacks, various size options, and easy assembly — the Carbon XL frame will be an excellent choice.
