Temperature Sensor for SkyRC Chargers — Safety and Accuracy During Charging
The temperature sensor for SkyRC chargers is a compact and reliable device designed for continuous monitoring of battery temperature during charging. The device is ideal for owners of drones, quadcopters, and other models that run on lithium batteries. This accessory is compatible with the product category: Drones and Quadcopters > Chargers and provides an additional level of protection during the operation of charging stations.
Description and Purpose
The sensor connects wired to a compatible charger using a standard 3-pin connector. It attaches directly to the battery case with a strap and transmits real-time temperature data to the charger. In case of overheating, the charger can automatically reduce power or stop the charging process, which significantly reduces the risk of battery damage and increases overall safety.
Key Advantages
- Automatic temperature control during battery charging.
- Protection against overheating and possible battery damage.
- Compatibility with popular SkyRC charger models and other compatible devices.
- Compact device dimensions and a convenient fastening strap for securing to the battery.
The sensor is especially important when working with lithium batteries (LiPo, LiFe, LiIo), which are sensitive to temperature increases: using the device helps extend battery life and increase charging safety.
| Parameters | Value |
|---|---|
| Supported battery types | LiLo, LiPo, LiFe, NiMH, NiCD |
| Compatible charger models | iMAX B6/B6AC/S60/D250 |
| Temperature range | 0 to 80 °C |
| Connector | 3 pin |
| Cable length | Approximately 40 cm |
| Total strap length | Approximately 20 cm |
| Sensor dimensions | 1.8 x 2.2 x 0.8 cm |
| Country of manufacture | China |
| Maximum measurement range | 80 |
| Minimum measurement range | 0 |
Technical specifications guarantee accurate readings in the range of 0 to 80 °C, allowing it to work with both low-voltage batteries and powerful lithium batteries for modeling and drones. The compact dimensions of the sensor (1.8 x 2.2 x 0.8 cm) make it unobtrusive when installed, and the cable length of about 40 cm ensures convenient connection regardless of the battery configuration.
Package contents:
1 x SkyRC Temperature Sensor for Chargers
This sensor will be an indispensable addition for owners of iMAX B6, B6AC, S60, D250 charger models and other compatible devices. The ease of connection and measurement accuracy allow it to be used both in domestic conditions and in professional environments where stability and safety are important when charging batteries for drones, quadcopters, and other equipment.
If you work with lithium-ion or lithium-polymer batteries, installing such a sensor is a simple and effective step to protect the battery and equipment from overheating and premature wear. Manufacturer: SkyRC. Product category: Drones and Quadcopters > Chargers.
