ADVANTAGES

 - Used in heating systems with forced circulation of heat transfer fluid (water) in premises (apartments, residential buildings, shops, etc.).

 - Reduced noise level due to the use of relays as a switching element

 - Equipped with a circulation pump

 - Three power adjustment stages

 - High-precision thermostat with 1°C hysteresis ensures smooth regulation and maintenance of heat transfer fluid temperature and reduced energy consumption

 - Protection against overheating of the heat transfer fluid

 - Possibility to connect a room thermostat and programmer

 - Connection to the heating system: direct supply pipe (G3/4) – in the upper part of the boiler, return pipe (G1) – in the lower part

 - Indication of network connection and emergency status

 - Steel tank and pipes with zinc coating, stainless steel heating elements ensure high corrosion resistance

 - High-quality Wilo pump

 - Enclosure protection rating – IP22

 - Warranty – 24 months

 - Extensive network of service centers

SPECIFICATIONS

Installation method: wall-mounted

Number of circuits: single-circuit (heating)

Heat output: 6 kW

Number of heating elements: 3

Number of power stages: 3 (2.0/4.0/6.0)

Connection type: single-phase / three-phase

Supply voltage: 230 V / 3x400 V

Maximum operating temperature of heat transfer fluid: 85° (±5)

Coating: zinc-coated steel

Control: mechanical

Enclosure protection rating: IP22

Class of protection against electric shock: Class 1

Nominal operating pressure: 0.2 MPa

Heat transfer fluid volume: 2.2 L

Device dimensions: 750x225x153 mm

Packaged dimensions: 780x230x160 mm

Device weight: 11.2 kg

Packaged weight: 12.2 kg

Country of manufacture: Ukraine

Brand registration country: Ukraine

Warranty: 24 months

Service life: 10 years

Color: white
