Wall-mounted
Battery-powered electronic ignition
Power regulation
Safety devices:
 - draft control device
 - overheat protection
 - ionization flame control electrode
 - pressure control sensor
 - safety relief valve
Hot water flow at T=25K: 15 l/min.
Power: 7 – 26.2 kW
Heat load: 8.1 – 29.6 kW
Efficiency: 86%
Gas parameters:
 - permissible natural gas pressure: 13 mbar
 - permissible liquefied gas pressure (butane/propane): 30 mbar
 - natural gas consumption at maximum power: 3.2 m3/h
 - liquefied gas consumption at maximum power: 2.4 kW
Domestic hot water preparation
 - temperature: 35 - 60 °C
 - hot water flow at T=25K: 2 - 7.5 l/min.
 - hot water flow at T=50K: 4 - 15 l/min.
 - maximum water pressure 12 bar
Flue gas parameters
 - temperature at maximum power: 180 °C
 - flue gas mass flow at maximum power: 79 kg/h
 - chimney connection diameter: 132.5 mm
Device dimensions: 655x425x220 mm
Weight in packaging: 16 kg
