Protection Class

• MIL-STD 810H certified (Drop, Shock, Vibration, Rain, Dust, Altitude, Freeze/Thaw, High/Low Temperature, Temperature Shock, Humidity)
• Tested with 26 drops from 1.2 meters on all sides
• IP 53 certified
• Aluminum-magnesium alloy chassis
• Protective port covers
• Easily removable battery and storage drive

OPERATING SYSTEM

• Windows® 11 Pro 64-bit

PROCESSOR

• Intel® Core™ i5-1135G7 (11th Gen) Processor 2.4 GHz with Turbo Boost Technology up to 4.2 GHz, 8 MB Cache

GRAPHICS

• Intel® UHD Graphics

MEMORY

• 16GB (2 x 8GB)
• 2 slots from 8GB to 64GB (2400-3200MHz DDR4)

STORAGE

• 512GB PCIE SSD

DISPLAY

• 14" FHD (1920 x 1080) Full HD

AUDIO

• Intel® High Definition Audio compatible
• Built-in speakers x 2
• Volume and mute control from keyboard

CAMERA

• No webcam

KEYBOARD AND INPUT

• 2 user-definable keys (P1/P2)
• RF signal slider switch
• Standard membrane keyboard (no LED backlight)

COMMUNICATION

• Integrated 10/100/1000 Ethernet
• Intel® Wi-Fi 6 AX201 (802.11a/b/g/n/ac/ax)
• Bluetooth® V5.2

SECURITY

• Intel® vPro™ Technology (for each CPU variant)
• TPM 2.0
• NIST BIOS compliant
• Easily removable SSD
• Stealth mode
• Kensington lock

I/O INTERFACES

• USB 3.2 Gen 2 (type A) x 2
• USB 3.2 Gen 2 (type C) x 1 (DP support)
• USB 2.0 (type A) x 1
• Audio in/out (combo jack) x 1
• SD card (SDXC) x 1
• 10/100/1000 Ethernet (RJ45) x 1
• VGA port (D-sub, 15-pin) x 1
• HDMI port (type A) x 1
• Serial port (RS232/RS422/RS485: D-sub, 9-pin) x 1
• DC-In jack x 1

MEDIA BAY (Only one option from below)

• Optional DVD super multi
• Optional secondary battery
• Optional secondary SSD for media bay
• Optional ExpressCard 54 x 1 or PCMCIA Type II x 1
• Optional 2nd RJ45 port and 2nd serial port (RS232)

POWER

• AC adapter: 100-240 V, 50-60 Hz, 90 W

ENVIRONMENTAL

• Temperature
  • Operating: -20°C ~ 60°C / -4°F ~ 140°F
  • Storage: -51°C ~ 71°C / -60°F ~ 160°F
• Humidity: 5% ~ 95%

DIMENSIONS AND WEIGHT

• 350 mm (L) x 282 mm (W) x 38 mm (H)
• 2.3 kg

WARRANTY

• Standard three-year limited warranty
