Monitor Technical Specifications

General Characteristics

• Diagonal: 23.8"
• Active Area (H × V): 527.04 × 296.46 mm (20.75" × 11.67")
• Screen Area: 156,246.28 mm² (242.18 in²)
• Panel Type: IPS (In-Plane Switching)
• Maximum Resolution: 1920 × 1080 (Full HD)
• Refresh Rate: 100 Hz
• Aspect Ratio: 16:9
• Pixel Pitch: 0.2745 × 0.2745 mm
• Pixel Density: 92.53 PPI

Image Quality

• Brightness: 250 cd/m² (typical)
• Contrast Ratio: 1500:1 (typical)
• Color Support: up to 16.7 million colors
• Color Gamut: 99% sRGB

Response Time

• 5 ms (Grey-to-Grey, fast mode)
• 8 ms (Grey-to-Grey, normal mode)

Viewing Angles

• 178° vertical / 178° horizontal

Coating and Backlight

• Anti-glare coating with 3H hardness
• Backlight: LED edgelight system

Eye Protection

• TÜV Eye Comfort: 4-Star
• Flicker Free: Yes

Interfaces

• 1× HDMI 1.4 (HDCP 1.4, up to 1920 × 1080 @ 100 Hz)
• 1× DisplayPort 1.2 (HDCP 1.4)
• 1× VGA
• 1× USB 3.2 Gen1 Type-B (upstream)
• 3× USB 3.2 Gen1 Type-A (downstream)
• 1× USB 3.2 Gen1 Type-C downstream (up to 15 W PD, data transfer only)
• USB Power Delivery: up to 15 W (via USB-C downstream)

Ergonomics

• Adjustments: height, tilt, swivel, pivot
• Height: up to 150 mm (5.9")
• Tilt: -5° / +21°
• Swivel: ±45°
• Pivot: ±90°
• VESA Mount: 100 × 100 mm

Power

• Input Voltage: 100–240 V AC (50/60 Hz ±3 Hz)
• Current: 1.5 A (typical)
• Consumption:
  • Off: 0.3 W
  • Standby: 0.3 W
  • Operating Mode: 11.7 W
  • Maximum: 65 W
  • POn: 12.0 W
  • TEC: 38.4 kWh

Audio

• Audio Output: optional soundbar (sold separately)

Security

• Kensington security-lock slot

Software

• Compatible with Dell Display Manager (Easy Arrange)
• Remote Asset Management

Operating Conditions

• Temperature:
  • Operating: 0°C – 40°C
  • Storage: -20°C – 60°C
• Humidity:
  • Operating: 10% – 80% (non-condensing)
  • Storage: 5% – 90% (non-condensing)
• Altitude:
  • Operating: up to 5,000 m
  • Storage: up to 12,192 m

Energy Efficiency and Standards

• ENERGY STAR: certified
• EPEAT Gold
• EPEAT Climate+
• TCO Certified Displays / Edge
• RoHS: compliant
• BFR/PVC free (excluding external cables)
• Arsenic-free, mercury-free (panel)

Mounting

• VESA: 100 × 100 mm

Package Contents

• Monitor
• Stand (base + riser)
• Quick Setup Guide
• Safety and Regulatory Information

Cables Included

• 1× power cable
• 1× DisplayPort–DisplayPort (1.8 m)
• 1× USB-A to USB-B (1.8 m)
• 1× HDMI–HDMI (1.8 m, in select countries)

Physical Characteristics

• Height with Stand (min–max): 364.00 – 496.53 mm
• Width with Stand: 538.64 mm
• Depth with Stand: 181.75 mm
• Height without Stand: 314.23 mm
• Width without Stand: 538.64 mm
• Depth without Stand: 50.03 mm
• Panel Weight (VESA): 3.12 kg
• Weight with Packaging: 6.78 kg
