FPV Bomber Drone Freedom-146 by WINGED LIBERTY FACTORY
Introducing the powerful and reliable FPV bomber drone Freedom-146, designed for demanding tasks and extended flights. This model combines carbon fiber strength, high-performance electronics, and the ability to carry a significant payload, making it an excellent choice for professional operators, industrial applications, and FPV enthusiasts.
Key Features
- 1. Maximum Power and Reliability – FPV drone with 480KV motors capable of lifting up to 11 kg of weight.
- 2. The Diatone Mamba Ultra 2500 mW transmitter ensures high stability and transmits signals over long distances up to 30 km.
- 3. The collapsible design allows for easy attachment and detachment of arms, ensuring compactness during transport.
- 4. It is recommended to use two or three 6s3p 12600mAh batteries to ensure high efficiency and long flight time.
Technical Specifications
| Parameter | Value |
|---|---|
| Model | Freedom-146 |
| Brand | WINGED LIBERTY FACTORY |
| Product Type | Drones & Quadcopters > FPV Drones |
| Frame | Carbon 14 inches |
| Receiver | ELRS 915 |
| VTX | Diatone VTX 1.5w 1.2GHz / Diatone Mamba Ultra 2500 mW |
| Stack | WLF80R 6S |
| Motors | WLF 4720 480KV |
| Propellers | GF1410 |
| Operating Temperature | from -20°C to 50°C (operates in winter) |
| Weight | 4850 g |
| Additional Load | +11000 g |
| Receiver Installation Option | PNP / TBS NanoRX / ELRS 915 / ELRS 720-1020MHz |
| Recommended Battery | 2x 6s3p 12600mAh |
| Flight Time | 30-80 min |
Package Contents
- 1 x Bomber "Freedom-146" 6S Analog
- 3 x boxes with two arms
- 1 x antenna
- 6 x propellers
- 6 x battery straps
The Freedom-146 is designed for tasks requiring high payload capacity and long flights. Thanks to WLF 4720 480KV motors and the WLF80R 6S stack, the drone withstands intense loads, while the optional Diatone Mamba Ultra 2500 mW ensures video transmission and control over long distances. The 14" carbon fiber frame guarantees rigidity and minimal structural weight, and the collapsible design facilitates transport and maintenance. Recommended power from two 6s3p 12600mAh batteries allows for flight times of 30 to 80 minutes, depending on the load and flight style.
This drone is suitable for industrial applications, aerial photography, small and medium-sized cargo delivery, and experimental tasks requiring combined range and payload capacity. The model is compatible with various receivers and PNP configurations, offering flexibility for integration into your control systems.
If you are looking for a reliable FPV bomber with a large payload, long flight time, and professional video capabilities — the Freedom-146 from WINGED LIBERTY FACTORY will be an excellent choice.
